Oil Filter, VW LIGHT SERIES, 7.90 1987-1994, D 229-4
- VW
- LIGHT SERIES
- 7.90
- Engine parts
- Lubrication
- Oil Filter
Manufacturer
Products: 2
Filters
Oil Filter
Oil Filter
Diameter:
93,2 mm
Height:
151 mm, 140 mm
Thread Size:
1" 12UNF-2B, 1"-12UNF-2B, 1"-12UNF-2B
1" 12UNF-2B, 1"-12UNF-2B, 1"-12UNF-2B
Seal Diameter:
72 mm, 62,0, 72,0 mm
Diameter 2:
72,0 mm
Connecting thread:
1"-12UNF-2B, 1" 12UNF-2B
Inner diameter:
62 mm
Outer diameter:
93.2 mm
Tightening Torque:
20 Nm
Valve type:
Overflow Valve
Filter type:
Screw-on Filter, Spin-on Filter
Screw-on Filter, Spin-on Filter
With one anti-return valve
Part number of the recommended special tools:
OCS 2
Packaging length:
9,6 cm
Packaging width:
9,60 cm
Packaging height:
15,30 cm
Net Weight:
581 g
Oil Filter
Oil Filter
Height:
142 mm
Thread Size:
1"-12UNF-1B, 1-12 UNF
Outer diameter:
93 mm
Filter type:
Screw-on Filter
With one anti-return valve
Outer diameter 2:
71 mm
Inner diameter 2:
62 mm
Bypass Valve Opening Pressure:
2.5 bar
Part number of the recommended special tools:
LS 9
Gasket inside diameter:
62 mm
Gasket outside diameter:
71 mm
